MMO Discrete Anodes Copper Core Linear Anode For Cathodic Protection System

MIXED METAL OXIDE ACTIVATED TITANIUM WIRE PIGGYBACK ANODES Activation: Noble Mixed Metal Oxides consisting of IrO2 and Ta2O5 Substrate Material: Titanium to ASTM Grade 1 or 2 Working Environment: Evolution of O2, Cl2 or a combination of both Nominal Design Life: Typically 20 years when operating at an anode current density of 100 A/m2 – coating loading can be adjusted for any combination of current output and design life. Dimensions of Piggyback Anode: Dimension of Ti Wire: 1.5 mm dia. or 3 mm dia. Current Output of Piggyback : 1.5 mm dia. Ti Wire – 0.5 A/m ; 3.0 mm dia. Ti Wire – 1A/m Lengths: From 1 m to 50 m* *Longer lengths are available on request Header Cable: Typically 10 mm2 or 16 mm2 XLPE/PVC connected to the MMO/Ti wire anode every 10 m, header cable or spacing between connections can be adjusted to suit the particular soil resistivity of operation Cable Tail: a cable tail, typically of 1 m to 5 m can be provided at one end or both ends of the Sock Anode to allow connection to the power feed from the TR

Applications 3mm Ø wire New Construction Tank Bottom CP Replacement Tank Bottom CP Applications 1.5mm Ø wire Parallel Anode Pipeline CP Underground Cable Ducts CP

Easy to Install ‐‐ Cost Effective o Arrives on site Ready to Lay in Place o Follows Structure Symmetry so achieves maximum cathodic protection efficiency by running a continuous anode parallel to the cathode. o 100% Factory Connections – high QC o Continuous Anode Technology o Optimized Current Distribution o Optimized Power Efficiency o Optimized Low Groundbed Resistance

Contact me for quotations:

Vivian Jiang

-----------------------------------------------

China Hunan High Broad New Material Co.Ltd.

70 Chezhan North Road,Changsha, China 410100

Tel:+86-731-85717705 Fax:+86-731-85716569

Mobile/Whatsapp: +86-139-7488-3816

Email: vivian@hbnewmaterial.com

Skype: vivian.jjy

China Hunan High Broad New Material was founded in 2006, focus on the business in advanced new material and service. Including: design, installation, material , engineering, maintenance and technical support.

Our sales office located in Changsha, Hunan province, plant located in Hunan,Shanxi, Henan,Guizhou province.Our business scope including : Cathodic protection products for fresh water and marine anti-corrosion products such as magnesium anodes,Aluminum anodes ,Zinc anodes etc.;Master alloy for aerospace ; Aluminum alloy , Magnesium investment castings industry; Magnesium alloy profile :Extrusion/hot rolled billet, plates,bars etc .for various civil & military industry,such as grade AZ31B,AM80,WE43,ZK60 etc.; high wear-resistance & hardness ceramic products for sandblasting nozzle & bulletproof plate for armor vest, armor vehicle.

Along with strong economic development  in China, we expand our business very well, Product capacity is over 5000mt per year.Turnover reach to USD20,000,000.00 per year.

Our Products are widely accepted and recognized by clients worldwide including Europe, North America, East Asia, Middle east etc..

Our R&D department have strong technical design capacity. We closely cooperated with colleges and universities, supply the service for various companies in China and overseas.

Believe we can be your long term and reliable supplier .
